QUICK OVERVIEW

tapeweb

  • Single-sided black UV tape available in 2", 3", 4" widths.
  • No VOCs
  • No primer required
  • UV stable
  • Seals VaproShield membranes and flashings
  • Seals penetrations, fasteners and clips
  • Waterproof and airtight
  • All weather application from minus 20°F to 170°F (minus 6.6° – 77° C)
  • Flexible and easily conforms to various shapes



Overview

VaproTape is an aggressive butyl rubber adhesive sealing tape. It is singled-sided, UV stable, and black in color. Available in 2", 3", 4" widths.

BASIC USE

VaproTape is used to stop water egress or air penetration on multiple surfaces and materials.

MATERIALS

Polyolefin surface, transparent adhesive, white paper release liner.

Resources

Technical Overview

Compatibility

All VaproShield products, concrete, plywood, OSB, metal, curbs, vents, AC systems and roof penetrations. Contact VaproShield Technical – if you have additional compatibility questions.

PHYSICAL PROPERTIES

Property

Value

Color

Black

Ultra Violet Light Exposure

UV Resistant

Application Temperature

-20°F (-6.6°C) - 170°F (77°C)

Service Temperature

-70°F (-57°C) to 200°F (93°C)

Shelf Life

5 years



SIZES/PACKAGING
  2”W (50.8mm) x 50’ (15m) 3”W (76.2mm) x 50’ (15m) 3”W (76.2mm) x 100’ (30.48m) 4”W (102mm) x 50’ (15m)
Part No: 60302585 60303585 60309580 60304585
Roll Weight 1.5 lbs (0.68 kg) 2.25 lbs (1.0 kg) 5.75 lbs (2.2 kg) 3 lbs (1.4 kg)
Case 24 Rolls 16 Rolls 8 Rolls 12 Rolls



TESTING DATA

Property

Standard

Result
Thickness

0.66 mm (26 mils)
Dry Tensile Strength

ASTM D882 Standard Test Method for Tensile Properties of Thin Plastic Sheeting

2.6 N/m (15 lbf/in)
Elongation

ASTM D882 Standard Test Method for Tensile Properties of Thin Plastic Sheeting

>700%

Water Vapor Transmission
Water Method

ASTM E96 Standard Test Methods for Water Vapor Transmission of Materials

<0.05 Perm (grain/h•ft2•inchHg
<0.35 g/ 24 hr•m2
