VaproMat

QUICK OVERVIEW

dblmattest2 3mm, 7mm (Black) VaproMat™ with attached Filter Fabric applied over WrapShield SA® WRB/AB creates a cost effective, positive drainage cavity.Lightweight, hydrophobic polyester filter fabric with an attached polyproplene drainage matrix. Installed over VaproShield WRB/Air Barriers, it creates a positive drainage cavity behind cladding, promoting rapid drying of the building envelope.

3mm, 7mm drainage matrix
Ideal for use with stucco or cultured stone
Filter backing keeps drainage cavity clean during lath and plaster
Easily works with traditional cladding systems such as metal panels, composite panels, and wood siding
Increases building envelope drying capacity
3mm recommended for use in arid climates requiring minimum drainage and where cavity depth is restricted due to design constraints
7mm recommended for mixed climates and high humidity to maximize drainage and drying from liquid water and reverse vapor drive

Typical VaproMat Applications

Physical Properties

Property	VaproMat 3mm	VaproMat 7mm
Color	Black/Black	Black
Roll Weight	27 lbs (12.3 kg)	20 lbs (9 kg)
Net Roll Size and Coverage	48” x 100’ (1.3m x 30.5m) 400 S/F (37.2 S/M)	48” x 65’ (1.23m x 19.8m) 260 S/F (24.2 S/M)
Gross Roll Size and Coverage	51” x 100’ (1.3m x 30.5m) 425 S/F (39.5 S/M)	51” x 65’ (1.29m x 19.8m) 276 S/F (25.6 S/M)
Skid	9 Rolls	9 Rolls
VOCs	None
Ultra Violet Light Exposure	90 days maximum
Minimum Temperature Application	Unlimited
Service Temperature	minus 40°F (-40°C) - 225°F (107°C)
Warranty	20 year material warranty

VaproMat Testing

Property	Standard/Test	Result
Flamespread Index	ASTM E-84	0 - Class A PASS
Smoke Developed Index	ASTM E-84	100 - Class A PASS
Drainage Test	ASTM E2273 Standard Test Method for Determining the Drainage Efficiency ofASTM E2273 Standard Test Method for Determining the Drainage Efficiency ofExterior Insulation and Finish Systems (EIFS) Clad Wall Assemblies	Exceeds Required 90%
